Supplier

INTCO

Overview

  • Rigid frame with a foldable back design for daily use
  • Excellent maneuverability
  • Option of a basic foam contour cushion or a PRC (additional cost)

Intended Users

  • Active children and adults without postural support needs who regularly use a wheelchair in urban or semi-urban environments
  • PRCs are recommended for users who need increased pressure management and positioning. Lack of and/or poorly fitted PRCs can result in health complications which can lead to death.





Price list available upon request.

Contact a sales agent for a free quote.



This product has been approved by the Product Advisory Council.

PRODUCT DETAILS

  • Rigid, steel frame
  • Adjustable backrest height and angle
  • Fold-to-seat back with quick folding mechanism
  • Seat material is a sling design made of high strength 600D nylon Oxford fabric with PVC coating
  • Option of a basic foam contour cushion or a PRC (additional cost)
  • Quick release rear adjustable axle
  • Fully adjustable foot support
  • Basic tool kit for maintenance included, plus tire pump and tire repair kit
  • Certifications: ISO 13485
  • Conformity with CE mark
  • Passed ISO 7176
  • For details on the CLASP warranty, click here. All wheelchairs must be registered in order to activate warranty coverage.

SIZES

Manufacturer Product Number YK9097-300 YK9097-350 YK9097-400 YK9097-450 YK9097-500
Seat Width 12″ (30 cm) 14″ (35 cm) 16″ (40 cm) 18″ (45 cm) 20″ (50 cm)
Seat Depth Adjustable from 16.5″ – 18″ (42 – 46 cm) depending on size
Back Height Fold-to-seat back with quick folding mechanism, height not specified
Back Angle Seven angle settings from 78° to 114° at 6˚ intervals
Footrest Height Adjustable from 11″ – 15″ (28 cm – 38 cm) depending on size
Rear Wheel Dimensions

24″ x 1.5″ diameter (60 cm x 3.8 cm)

Wheelbase length is adjustable from 14.37″ – 17.32″ (36.5 cm – 44 cm)

Rear Wheel Axle Adjustability Adjustable at seven settings each 1.3 cm apart
Caster Dimensions 5″ x 2″ diameter (12.7 cm x 5 cm)
Overall Width Open 21″ (53 cm) 23″ (58 cm) 25″ (63 cm) 27″ (68 cm) 29″ (73 cm)
Overall Length 34″ (86 cm) 36″ (91 cm)
Product Weight 43.9 lb – 49.4 (19.9 kg – 22.4 kg), 39 lb (17.7 kg) without rear wheel 44.5 lb – 50 lb (20.2 kg – 22.7 kg), 39.7 lb (18 kg) without rear wheel 45.3 lb – 50.8 lb (20.55 kg – 23.05 kg), 40.5 lb (18.35 kg) without rear wheel 46.3 lb –51.8 lb (21 kg – 23.5 kg), 41.4 lb (18.8 kg) without rear wheel 46.5 lb – 53.02 lb (21.1 kg –24.05 kg), 42.7 lb (19.35 kg) without rear wheel
Weight Capacity 220 lb (100 kg)
Packaging One unit per carton
Package Size 26″ x 28″ x 20″ (65 cm x 70 cm x 50 cm)
Package Weight 49.4 lb (22.4 kg) 50 lb (22.7 kg) 50.7 lb (23 kg) 51.8 lb (23.5 kg) 52.9 lb (24 kg)



ACCESSORIES

Toolkit included:

  • 1 Hex socket 10 mm
  • 1 Hex wrench 19 mm
  • 2 Hex wrenches 10 mm – 13 mm
  • 1 Hex socket 17 mm – 19 mm
  • 1 Pump
  • 1 Bicycle tire repair Kit

SUPPORT MATERIALS

Product Information Sheet

Download

Fiche d’information sur le produit en français

Télécharger

Página de Información en español

Descargar

User Manual

Download

Assembly Guide

Download

PROVISION

Important:  This wheelchair should be provided by a therapist trained in the Wheelchair Service Training Package – Basic Level.

Have questions about how the ordering process works?

Find the most appropriate product for the people you serve.
